They are primarily used in HVAC and refrigeration systems.
Made of copper, they offer excellent corrosion resistance and thermal conductivity.
Designed to distribute refrigerant flow to various parts of the system.
Typically applied in Variable Refrigerant Flow (VRF) systems.
Available in multiple sizes to accommodate different pipe diameters.Specification
|
Type |
Port A Diameter |
Port B Diameter |
Port C Diameter |
|
|
Y1 |
Gas pipe |
12.7/15.9/19.1 |
9.6/12.7/15.9 |
12.7/15.9 |
|
Liquid pipe |
9.6 |
6.35/9.6 |
6.35/9.6 |
|
|
Y2 |
Gas pipe |
19.1/22.3 |
15.9/19.1 |
12.7/15.9/19.1 |
|
Liquid pipe |
9.6/12.7 |
9.6/12.7 |
6.35/9.6/12.7 |
|
|
Y3 |
Gas pipe |
22.3/25.4/28.6 |
19.1/22.3/25.4/28.6 |
9.6/12.7/15.9/19.1 |
|
Liquid pipe |
9.6/12.7/15.9 |
9.6/12.7/15.9 |
6.35/9.6/12.7 |
|
|
Y4 |
Gas pipe |
35/38.1/41.2 |
28.6/35/41.2 |
19.1/22.3/25.4/28.6 |
|
Liquid pipe |
15.9/19.1 |
12.7/15.9/19.1 |
9.6/12.7/15.9 |
|
|
Y5 |
Gas pipe |
41.2/54/44.5 |
35/41.2/54 |
25.4/28.6/35 |
|
Liquid pipe |
19.1/22.3 |
15.9/19.1/22.3 |
12.7/15.9/19.1 |
|
|
Y6 |
Gas pipe |
35/41.3/54 |
25.4/28.7/35/41.3 |
25.4/28.7 |
|
Liquid pipe |
15.9/19.1/22.3 |
12.7/15.9/19.1/22.3 |
12.7 |
|
|
Y7 |
Gas pipe |
69.8/60.3/54 |
35/41.3/54 |
41.3/35 |
|
Liquid pipe |
19.1/22.3/25.4 |
15.9/19.1/22.3/25.4 |
15.88 |
|
|
Y8 |
Fittings |
One fitting for chosing |
||
|
Liquid Pipe |
22.2/25.4 |
15.9/19.1 |
19.1/25.4 |
|
|
Y9 |
Gas Pipe |
28/32/35/38.1 |
25.4/35 |
25.4/35 |
|
Liquid Pipe |
19.1 |
15.9 |
15.9 |
|
|
Y10 |
Gas Pipe A |
28/32/35/38.1 |
25.4/35 |
25.4/35 |
|
Liquid Pipe A |
25.4 |
19.1 |
12.7/15.9 |
|
|
Gas Pipe B |
35/38.1/41.3 |
35 |
25.4/35 |
|
|
Liquid Pipe B |
19.1 |
15.9 |
15.9 |
|
|
Y11 |
Gas Pipe A |
42/45 |
42 |
35/42/45 |
|
Liquid Pipe A |
35/38/45 |
35 |
25.4 |
|
|
Gas Pipe B |
28/32/35/38 |
25.4 |
25.4 |
|
|
Liquid Pipe B |
25.4 |
19.1 |
12.7/15.9 |
|
|
Accessory |
11 optional pieces |
|
||
