Safe and durable construction
Stable and smooth operation
All-copper motor for reliable performance
High efficiency with energy-saving operation
Eco-friendly design
Strong airflow output
Easy to install
Powerful air delivery
Rein thickened housing for enhanced durability
Specification
The centrifugal fan features a compact design, easy installation, smooth operation, low noise, and high energy efficiency. It offers multiple speed control options and is widely used in refrigeration and ventilation applications, such as condensers, evaporators, duct fans, and ceiling fans.
Motor Voltage:
Single-phase: 110–120V, 60Hz / 220–240V, 50/60Hz
Three-phase: 380V, 50/60Hz (custom voltage available upon request)
Protection Rating: IP44 or IP54 (FLJ series)
Service Life: Over 30,000 hours
Operating Temperature Range: –30 °C to 60 °C
|
Item Code |
Model |
Power |
Voltage(V) |
Speed(r/min) |
Air Flow (m3/min) |
Pressure(Pa) |
Noise(dBA) |
|
HC-YWF(K) |
130FLJ0 |
60W |
220V/380V |
2200 |
3.2 |
280 |
70 |
|
HC-YWF(K) |
|||||||
|
HC-YWF(K) |
130FLJ1 |
85W |
220V/380V |
2200 |
3.6 |
280 |
70 |
|
HC-YWF(K) |
130FLJ5 |
120W |
220V/380V |
2600 |
5.5 |
350 |
72 |
|
HC-YWF(K) |
150FLJ7 |
240W |
220V/380V |
2650 |
9.5 |
450 |
73 |
|
HC-YWF(K) |
150FLJ7 |
330W |
220V/380V |
2800 |
11 |
460 |
75 |
|
HC-YWF(K) |
170FLJ3 |
400W |
220V/380V |
2800 |
13 |
550 |
76 |
|
HC-YWF(K) |
170FLJ7 |
500W |
220V/380V |
2800 |
15 |
630 |
76 |
