Specification
The motor features a built-in automatic reset thermal protector and NSK ball bearings.
Designed as an outer rotor motor, it offers a compact structure, small size, stable performance, and a working life of up to 50,000 hours.
The fan blade utilizes an advanced aerodynamic design for high efficiency and low noise operation.
The fan is balanced on both sides for minimal vibration, with a balance precision grade of G2.5.
Its uniquely designed bracket allows for easier and more flexible installation, with no maintenance required.
Protection rating: IP44; Insulation class: [Please specify if available].
|
Item Code |
Model (No) |
Voltage (V) |
Power (W) |
Speed(r/min) |
Air volume (m³/h) |
Full-voltage (pa) |
Noise dB(A) |
|
HC-FZY-YT |
100 |
220 |
75 |
2650 |
250 |
350 |
30 |
|
HC-FZY-YT |
125 |
220 |
85 |
2650 |
275 |
390 |
32 |
|
HC-FZY-YT |
150 |
220 |
140 |
2650 |
370 |
400 |
14 |
|
HC-FZY-YT |
160 |
220 |
145 |
2650 |
590 |
420 |
45 |
|
HC-FZY-YT |
200 |
220 |
180 |
2650 |
850 |
550 |
48 |
|
HC-FZY-YT |
250 |
220 |
190 |
2650 |
1000 |
570 |
51 |
|
HC-FZY-YT |
315 |
220 |
280 |
2650 |
1500 |
830 |
53 |
